35
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Onboard SATA Mode Enabled
SATA Configuration IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
OnBoard IR Disabled
Parallel Port Address 378
Parallel Port Mode Normal
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
Help Item
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
mn
< >
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Onboard SATA Mode (Enabled)
Use this item to enable or disable the build-in on-chip Serial ATA.
SATA Configuration (IDE)
Use this item to select the type of the build-in on-chip Serial ATA.
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
OnBoard IR (Disabled)
Use this item to enable or disable the onboard infrared port, and to assign a port
address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
DISABLED: disables the
integrated IDE
Controller.
Enabled: enables both
controllers.
To Next Page
