ECS B85H3-M7 User Manual

Chapter 3
B85H3-M7 USER MANUAL
60
Boot Override
Use this item to select the boot device.
Save Options
This item enables you to save the options that you have made.
Save Changes
This item enables you to save the changes that you have made.
Discard Changes
This item enables you to discard any changes that you have made.
Restore Defaults
This item enables you to restore defaults to all the setup options.
Discard Changes and Exit
This item enables you to exit system setup without saving any changes.
Discard Changes and Reset
This item enables you to reset system setup without saving any changes.
This page enables you to exit system setup after saving or without saving the
changes.
Exit Menu
Back to EZ Mode
This item enables you to back to EZ mode.
Save Changes and Exit
This item enables you to exitt the system setup after saving the changes.
Save Changes and Reset
This item enables you to reset system setup after saving the changes.
Save as User Defaults
This item enables you to save the changes that you have made as user defaults.
Restore User Defaults
This item enables you to restore the user defaults.
Main Advanced Chipset M.I.B. III Boot Security Exit
Go back to EZ Mode
Back to EZ Mode
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Discard Changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit

ECS B85H3-M7 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1666 MHz
System bus rate	5 GT/s
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	4
Supported storage drive interfaces	SATA II, SATA III
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC \\r ErP/EuP \\r WHQL \\r WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® B85
Audio output channels	5.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
BIOS type	AMI
ACPI version	5.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	180 mm
Width	225 mm
