ECS G31T-M User Manual

38
Using BIOS
SMART Fan Control (Disabled)
This item allows you to enable/disable the control of the system fan speed by chang-
ing the fan voltage.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Disabled
Smart Fan Function

Scroll to this item and press <Enter> to view the following screen:
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move

Options
ECS supports the latest PECI host technology. While using Wolfdale or
Yorkfield CPU, the original images of the BIOS item “PC Health Status”
and “Smart FAN Function” will be replaced by PECI mode and negative
number. (The max data from PECI is zero.)
Hardware Health Event Monitoring
Smart Fan Function Press Enter
System Temperature 33°C/91°F
CPU Fan Speed: 2537 RPM
SYS FAN Speed: 0 RPM
CPU Vcore: 1.280V
VDIMM: 1.840V
-=- PECI Mode-=-
Offset to TCC Activation Temp.: -20
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status

F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move


ECS G31T-M Specifications

General

Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
S/PDIF out connector	Yes
Graphics card	GMA 3100
Maximum graphics card memory	384 MB
LAN controller	Realtek RTL8101E
Networking features	Fast Ethernet
ACPI version	1.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
