Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
OnBoard SATA Controller Enhanced
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Onboard AUDIO Function Enabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
DISABLED: disables the in-
tegrated IDE
controller.
ENABLED: enables both
Controllers.
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
OnBoard SATA Controller (Enhanced)
This item allows you to enable or disable the onboard SATA controller.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or
BPP (Bi-Directional Parallel Port).
ECP Mode DMA Channel (DMA3)
Use this item to assign the DMA Channel under ECP Mode function.
To Next Page
