H110I-C4P
USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the H110I-C4P motherboard. This motherboard is a high
performance, enhanced function motherboard designed to support the LGA1151
socket for
Intel
®
Skylake processor.
This motherboard is based on Intel
®®
®®
®
H110 Express Chipset for best desktop platform
solution. It supports up to 32 GB
of system memory with dual channel DDR4 2133
MHz. High resolution graphics via one PCIe x16 Gen3 slot.
It integrates USB 2.0 and USB 3.0 interface, supporting up to five USB 2.0 ports (two
USB 2.0 ports at the rear panel, one 10-pin USB 2.0 header supports additional two
USB 2.0 ports and one 5-pin USB 2.0 header supports additional one USB 2.0 port)
and four USB 3.0 ports (two USB 3.0 ports at the rear panel and one USB 3.0 header
supports additional two USB 3.0 ports) .
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including PS/2 keyboard and mouse combo connector, two USB 2.0 ports, one RJ45
LAN connector, two USB 3.0 ports, one Display port, one HDMI 1.4 port, one type L
WiFi anttena connector (optional), and audio jacks for line-in, line-out and micro-
phone.
In addition, this motherboard supports four SATA 6Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
H110I-C4P Motherboard
Quick Installation Guide
User Manual
DVD
I/O Shield
2 SATA 6Gb/s cable
The package contents above are for reference only, please take the actual package items as
standard.
