ECS H55H-M User Manual

30
Using BIOS
Advanced Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced Setup
Help Item
For the processor its
CPUID belows 0F41h.
TM2 only can be enable
under below setting.
1.Freq.>=3.6GHz FSB800
2.Freq.>=2.8GHz FSB533
Thermal Management Enabled
TM Status TM1/TM2
Limit CPUID MaxVal Disabled
Enhanced Halt (C1E) Enabled
Intel XD Bit Disabled
Intel VT Enabled
Intel EIST Enabled
Intel (R) TurboMode tech Enabled
Factory default TDC limit value : 552
Factory default TDP limit value : 696
Quick Power on Self Test Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Hard Drive
2nd Boot Device CD/DVD
3rd Boot Device Removable Dev.
Boot Other Device Yes
ECS eJIFFY Function Disabled

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
Thermal Management (Enabled)
This item displays CPU’s temperature and enables you to set a safe temperature to
Prescott CPU.
TM Status (TM1/TM2)
This item shows TM function status if CPU can support TM function.
Limit CPUID MaxVal (Disabled)
Use this item to enable or disable the Max CPUID value limit. When supports
Prescott and LGA775 CPUs, enables this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
Enhanced Halt (C1E) (Enabled)
This item enables or disables enhanced halt (C1E).
Intel XD Bit (Disabled)
This item allows users to enable or disable the Intel XD bit.
Intel EIST (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep
technology).
Intel VT (Enabled)
When enabled, a VMM can utilize the additional hardware capabilities provided by
Vandor Poor Technology.
Intel (R) TurboMode tech (Enabled)
This item enables or disables Intel TurboMode Technology support.
Factory default TDC limit value (552)
This item shows the factory default TDC limit value.

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
