ECS H55H-M User Manual

36
Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status

-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
CPU Fan Speed : 885 RPM
CPU Vcore : 1.168 V
VDIMM : 1.504 V
-=- System Hardware Monitor-=-

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
Offset to TCC Activation Temp. : -52
Smart Fan Function (Press Enter)

Scroll to this item and press <Enter> to view the following screen:
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Disabled
Enabled
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU SMART FAN Control Enabled
SMART Fan Mode Normal
CPU SMART Fan start PWM 28
SMART Fan start PWM TEMP (°C)32
DeltaT +3
SMART Fan Slope PWM value 4
CPU Fan Full Speed Offset (-) 7
CPU SMART Fan Control (Disabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
