ECS H81H3-M5 User Manual

H81H3-M5 USER MANUAL
32
Chapter 3
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
 Smart Fan Function
CPU/System/Power Smart Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU/System/Power fan
speed by changing the fan voltage.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control Enabled
Smart Fan Mode
Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (DTS) 52
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Temperature (DTS) 40
System Temperature 28
0
C
CPU Fan Speed 3375 RPM
System Fan Speed 0 RPM
Power Fan Speed 0 RPM
Processor Input Voltage 1.764V
DIMM Voltage 1.548V
TCC Activation Temperature (DTS) 85
Smart Fan Function
PC Health Status
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unite
System Fan Full Speed Offset (DTS) 52
System Smart Fan Control Enabled
Smart Fan Mode Normal
Enable CPU SmartFan
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unite
Power Fan Full Speed Offset (DTS) 52
Power Smart Fan Control Enabled
Smart Fan Mode Normal
