Edison PRO User Manual

C. Unpacking and Setting up ∃DISON PRO
1. Create from SD
: To load a .x3g file from SD Card.
2. Preheat
: To preheat the hot-end(nozzle), in particular, in order to unblock the hot-end hole which was clogged by melting the filaments
accumulated inside the hot-end.
- Extruder : by setting ON/OFF you can start preheating of the extruder.
- Platform : by setting ON/OFF you can start preheating of the printing bed.
3. Utilities
: It leads to 12 different options for hardware. You do NOT want to change the settings without any specific explanation
because they are only for developers or after-sales service.
Monitor mode
: Shows current temperature of the extruder and printing status.
Filament loading
: To put the filament into the extruder or pull it out of the extruder
Display Menu Introduction
: To put the filament into the extruder or pull it out of the extruder
Preheat settings
: To set up temperature of the extruder and the printing bed
Pre-leveling
: To manually level the printing bed
Auto-leveling
: To level the printing bed before starting Auto-leveling
Home Axes
: To default the position of X, Y, Z axis
Bot Statistics
: Shows the operation time spent printing.
- Life Time: Total operation time of ∃DISON PRO
- Last Print: Last build time
- Filament: Total amount of filament used (in meter)
- Fil. Trip: Amount of filament used for the last
build (in meter)
Filament Odometer
: Not only this shows the filament information, but also you can
default the trip value here.
- Life: Total amount of filament used (in meter,
unable to reset)
- Trip: Amount of filament used for the last build
(in meter)
General Settings
: To configure sound, LED color or etc.
- Ditto Printing Off
- Override GCTemp OFF
- Pause with heat OFF
- Sound ON/OFF
- Heat LEDs ON/OFF
- LED Color : To change LED colors.
- Accelerate : To accelerate the extruder speed
- Extruders : To choose SINGLE or DOUBLE
- Extruder Hold ON/OFF
∃DISON PRO User Manual V.1 10
- Extruder Hold ON/OFF
- HBP Installed YES
- Tool Offset Sys NEW
- Check SD Reads YES
- P-Stop Control OFF
Profile
Home Offsets
Jog Mode
: To control manually the location of the extruder and the build
platform
* Press the 3D button to go back to the main
menu
Disable Steppers : To stop the motor.
Enable Steppers /Disable Steppers
Blink LEDs
: To make LED lamp flickering
Laser Blinking!
Stop Blinking
Calibrate Nozzles
Restore Settings :To initialize ∃DISON PRO
Eeprom
Version Information
: Shows the firmware version.
