Chapter 6 Reference
6-7. Preset Timings
The following table lists the factory preset analog signal timings:
Attention
• The display position may deviate depending on the connected PC, and may require screen adjustment using the Setting menu.
• If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after adjustment.
• When interlaced signals are used, the screen cannot be displayed correctly even after screen adjustment using the Setting menu.
EV2450
Resolution Applicable Signals
Frequency
Dot Clock: MHz Horizontal: kHz Vertical: Hz
640 × 480 VGA/CEA-861 25.18 31.47 59.94
640 × 480 CEA-861 25.20 31.50 60.00
640 × 480 VESA 31.50 37.8 6 72.81
640 × 480 VESA 31.50 37.5 0 75.00
720 × 400 VGA TEXT 28.32 31.47 70.09
800 × 600 VESA 36.00 35.16 56.25
800 × 600 VESA 40.00 37. 88 60.32
800 × 600 VESA 50.00 48.08 72.19
800 × 600 VESA 49.50 46.88 75.00
1024 × 768 VESA 65.00 48.36 60.00
1024 × 768 VESA 75.00 56.48 70.07
1024 × 768 VESA 78.75 60.02 75.03
1280 × 720 CEA-861 74.25 45.00 60.00
1280 × 800 VESA CVT 83.50 49.70 59.81
1280 × 1024 VESA 108.00 63.98 60.02
1280 × 1024 VESA 135.00 79.98 75.03
1600 × 900 VESA RB 108.00 60.00 60.00
1680 × 1050 VESA CVT 146.25 65.29 59.95
1680 × 1050 VESA CVT RB 119.00 64.67 59.88
1920 × 1080 CEA-861 148.50 67.5 0 60.00
