Chapter 6 Reference
6-6. Specications
LCD Panel Type IPS (Anti-Glare)
Backlight LED
Size 60 cm (23.8 inch)
Native Resolution 1920 dots × 1080 lines
Display Size (H × V) 527.0 mm × 296.5 mm
Pixel Pitch 0.2745 mm
Display Colors 8-bit colors: 16.77 million colors
Viewing Angle (H / V, typical) 178˚ / 178˚
Response Time (typical) Gray-to-gray: 14ms (overdrive setting: Off)
5ms (overdrive setting: Enhanced)
Video Signals Input Terminals DisplayPort (HDCP) × 1, HDMI TypeA (HDCP)
*1
× 1, DVI-D
(HDCP) × 1, and D-Sub mini 15-pin × 1
Digital Scanning Frequency
(H / V)
31 kHz to 68 kHz (DisplayPort, DVI), 15 kHz to 68 kHz (HDMI) /
59 Hz to 61 Hz (DisplayPort, DVI), 49 Hz to 61 Hz (HDMI) (VGA
TEXT: 69 Hz to 71 Hz)
Analog Scanning Frequency
(H / V)
31 kHz to 81 kHz / 55 Hz to 76 Hz
Synchronization Signal Separate
Max. Dot Clock 148.5 MHz
USB Port Upstream port × 1, downstream port × 2
Standard USB Specication Revision 3.0
Communication Speed 5 Gbps (super), 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Supply Current Downstream: Max. 900 mA per port
Audio Audio Input Format DisplayPort: 2ch linear PCM (32 kHz / 44.1 kHz / 48 kHz / 88.2
kHz / 96 kHz)
HDMI: 2ch linear PCM (32 kHz / 44.1 kHz / 48 kHz)
Speakers 1 W + 1 W
Headphones 2 mW + 2 mW (32 Ω)
Input Terminals Line: Stereo mini jack × 1
DisplayPort × 1, HDMI TypeA × 1 (shared with video signal)
Output Terminals Headphones: Stereo mini jack × 1
Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 0.75 A - 0.40 A
Maximum Power Consumption 42 W or less
Power Save Mode 0.5 W or less (no USB device connected, default settings)
Standby Mode 0.5 W or less (no USB device connected, default settings)
Physical
Specications
Dimensions Min. height: 537.7 mm × 322.7 mm × 190 mm (W × H × D)
(Tilt: 0˚)
Max. height: 537.7 mm × 506.6 mm × 199.1 mm (W × H × D)
(Tilt: 35˚)
Dimensions (Without Stand) 537.7 mm × 313.1 mm × 45.5 mm (W × H × D)
Net Weight Approx. 5.5 kg
Net Weight (Without Stand) Approx. 3.5 kg
Height Adjustment Range 180 mm (Tilt: 35˚) / 172.7 mm (Tilt: 0˚)
Tilt Up 35˚, down 5˚
Swivel 344˚
Vertical Rotation Left 90˚, right 90˚
Operating
Environmental
Requirements
Temperature 5 ˚C to 35 ˚C (41 ˚F to 95 ˚F)
Humidity 20 % to 80 % R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
