8
MAINTENANCE (starts at page 36)
ENGLAND
Caution! Switch off the engine and disconnect the spark plug before undertaking any
maintenance work.
MOWING BAR (starts at page 36)
H
M
F
G
ADJUSTMENT OF CUTTING HEIGHT
This adjustment must be carried out when the engine is not running. For this purpose disengage the two skids from the blade-holder (16), loosen screws (17), and then
either lmove the skids (16) above or below the blade (15) into the desired position. Finally tighten the whole unit with the respective screws.
ADJUSTMENT: This has to be carried out when the distance of the teeth
between the blade and the counter blade are not too for away from one another.
This operation should be carried out, when the blade unit is disassembled and
by clamping it in a vice. However it is also possible to make the adjustment with
the machine assembled, In this case the blade must be disengaged.For checking
move the blade by hand make sure that the wear-plates are not excessively
tightened.
To adjust the wear plates (T), individually. Turn screw (U) slightly. At each
adjustment of a wear-plate, the blade should be moved by hand for checking
that it can be moved without effort. The correct adjustment is obtained when
there is only the minimum possible distance between blade and counterblade (0.2 mm).
SHARPENING has to be carried out when the mower blade does not cut perfectly. For
this purpose, the blade must be sharpened bu an authrosied dealer.
When using the machine, it is suitable to grease the seat where the eccentric piece runs
at least one time every hour, and keep the blade clean and to lubricate the guides and to
oil the sliding surface between blade and counterblade.We recommend the blade to be
cleaned carefully when not used for long periods of time.
lCheck regulary all screws and nuts for tightness
lEngine: consult the engine manufacturers instruction manual supplied with your
products.
lWorking: if after pressing the control handle (4) the machine will not start, adjust the
control cable (18), inserting the tie rod (19) in one of the following holes (20) of the plate
(21)
lMoving on: if the machine will not proceed or remain in work, adjust the screw (22)
situated on the wheels control lever(2).
lReplacement of the driving belt: release the tie rod (19) from the control handle (4),
take off the protection guard (5), remove the belt (23).Replace the new belt and
reassamble as before.
lReduction gear (13): contains oil SAE 20/40, W140 about 0,5 kg.
Control the oil level through the cap (24).
The oil must be replaced after the first 50 working hours, and then after each 1000
hours.
Filling plug (24), drain plug (25).
