15
• Switch off at the mains.
• Close the water supply cock.
• Replace the filters and the overflow.
• Remove the top and bottom jets “F” and “I”,
unscrewing the ring nut “H”.
Figure 23
• Unscrew plugs “L” from the rinse jets and clean
using a water spray. Do not use sharp implements
to clean the nozzle holes, which could otherwise be
damaged.
• Remove filters “C” and “D” and clean them under a
water spray.
• Remove the filter “Z” and clean away any remained
food in order to avoid blocking the draining system.
Figure 24
Upon completion of cleaning operations, replace the
parts removed previously.
Cleaning the exterior surfaces
Before carrying out any cleaning operations, turn off
the power at the mains.
Clean the stainless steel surfaces using warm
soapy water; never use detergents containing
abrasive substances nor steel scrapers, common
wire wool, brushes or scrapers; rinse thoroughly
using a wet cloth and carefully wipe dry.
Clean the control panel using a soft damp cloth
and a neutral detergent if necessary.
Do not wash the appliance using direct or high-
pressure water jets.
To reduce the emission of pollutants into the environ-
ment, clean the appliance (externally and where
necessary internally) with products having a biodegra-
dability of over 90%).
C5 UNDERCOUNTER DISHWASHER WITH
INCORPORATED CONTINUOUS WATER
SOFTENER
These models have a continuous softener in the
dishwasher water circuit. By means of special resins,
this device removes the calcareous substances from
the feed water, supplying decalcified water for
washing.
For the continuous softener to work properly the resins
must be regenerated periodically, with frequency
depending on the hardness of the water and the num-
ber of wash cycles carried out.
Unlike conventional water softeners, this continuous
softener does not require machine stops for regenera-
ting the resins.
AUTONOMY OF A COLUMN OF RESINS
ACCORDING TO THE CHANGE IN INLET WATER
HARDNESS
Salt container
The water can only be softened if there is salt in the
special container. The salt container must be filled
when the dishwasher is used for the first time and
whenever the messages
SAL 0 or SAL END
are displayed at the start or end of a wash cycle.
No salt in the container
If the messages
SAL 0 or SAL END appear on
the display at the start or end of a wash cycle it means
that the salt container is empty Wash cycles can be
started just the same, even if the display signals no
salt; in which case the water used for washing is not
softened.
Z
1
2
°fH °dH °cH Number of
Cycles
15 8,4 10,5 14
20 11,2 14 10
25 14 17,5 7
30 16,8 21,1 6
35 19,6 24,6 5
40 22,4 28,1 4
The factory setting of max. outlet water hardness is 10 °fH/ 5.6
°dH/ 7 °cH.
IMPORTANT:
Only use coarse salt with a purity level of
99.8% NaCl. The use of salt with a lower
purity level can cause clogging of the salt
container filter and malfunctioning of the
water softener.
IMPORTANT:
Open the salt container only when the
messages
SAL 0 or SAL END are
displayed. Opening the cap when these
messages are not displayed can cause
spilling of the saline solution and com-
promise machine operation.
