Elka T 3000 User Manual

T 3000 - T 350
0
14
6 Technical data T 3000-3500
Range of application
Application for…
 Toll-station
Drive pulse
from...
 TCP/IP
 RS485
 Push button, card reader, desktop panel etc.
 Induction loops
Safety
 Force monitoring for barrier CLOSE
 Emergency release / vandalism protection
 Internal evaluation for safety contact profile (8.2kOhm)
 Connection of external safety systems
Table 2
General data
Supply voltage 88~264VAC
47~63Hz
Power consumption Max. 1.4A (230VAC)
Max. 2.8A (115VAC)
Duty cycle 100%
Temperature range -30°C to +70°C / -22°F to +158°F
Controller MO 24
Housing dimensions (L/W/H) 360x300x1.100mm
Foundation (frost-free) 550x500x800mm
Boom connector Left or right
Housing Aluminium
Mechanics Steel, galvanized
Sound pressure level (distance 1m) ≤ 60 dB(A)
Degree of protection IP 54
Table 3

Elka T 3000 Specifications

General

Brand	Elka
Model	T 3000
Category	Automatic Barriers
Language	English
