2013/1/28 13-1 A3ATCCA.fm
TYPE A
PARTS LIST [LF391EM4 (Serial No.: DS2)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY
Ref.No. Description Part No.
A3 REAR COVER A3AT0UH 1EM030207
A4-1 BOTTOM COVER R A3AT0UH 1EM030208
A4-2 BOTTOM COVER L A3AT0UH 1EM030209
A13 JACK HOLDER A3AU0UH 1EM334651
A15# RATING LABEL A3AT0UH ----------
A16 LOGO LABEL A3AU0UH ----------
A17 ENERGY GUIDE LABEL A3AT0UH ----------
AC601# AC CORD W/O A GND WIRE UL/CSA/1700/NO/
BLACK
WAC172LTE005
B10 STAND BRACKET A3AT0UH 1EM127821
B17 WALL MOUNT BRACKET A11N0UH 1EM434637
B18 WALL MOUNT COVER A2170UT 1EM332137
B23 WIRE LABEL A3AF0UT ----------
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
240MM
WX1A3AT0S106
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
195MM
WX1A3AT0S105
CL3801 WIRE ASSEMBLY 4PIN 4PIN/395MM&110MM WX1A3AT0C301
L7 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L23 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L24 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
SA1 STAND ASSEMBLY A3AT0UH 1ESA34650
SP3801 SPEAKER MAGNETIC 8Ω/8W S0310F15 DS08110XQ003
SP3802 SPEAKER MAGNETIC 8Ω/8W S0310F15 DS08110XQ003
SSK1 STAND SCREW KIT A3AT0UH(DOUBLE SEMS
SCREW M4X20 + BLK)
1ESA34649
PAC K IN G
S1 CARTON A3AT0UH 1EM334637
S3 STYROFOAM TOP A3AT0UH 1EM030605
S4 STYROFOAM BOTTOM A3AT0UH 1EM030606
S6 SET BAG A21P6UH 1EM334729
S7 SERIAL NO. LABEL A01PBUH ----------
S8 STAND BAG A17G0UH 1EM436162
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A31T0UH 1EMN30379
X3 REMOTE CONTROL UNIT NH303UD NH303UD
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A3AT0UH 1EMN30402
X7 REGISTRATION CARD (EMERSON) A17N1UH 1EMN27763A
X22 WARNING MESSAGE FLIER A3AU2UH 2EMN00059A
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U30T2R0
Consists of the following
A1 FRONT CABINET A3AT0UH 1EM030206
A6 CONTROL PLATE A31F0UT 1EM334317
A9 SENSOR LENS A3AF0UT 1EM334258
A21 BLIND LABEL A3AU0UH ----------
B12 SHIELD PLATE A3AF0UT 1EM334260
CL3011 FFC WIRE ASSEMBLY 51PIN(W/SHIELD) 51P/
FFC/SHIELD/664MM
WX1A3AT0P401
L7 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
LCD MODULE ----------
