2013/1/28 13-2 A3ATCEL.fm
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
FUNCTION CBA UNIT
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A3ATCMMA-002
Ref. No. Description Part No.
FUNCTION CBA UNIT A3ATCMSW-001
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following
A3ATCMPW-001
CAPACITORS
C602# SAFTY CAP. 2200pF/250V KX CA2E222MR101
C604# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C605 CAP ELE 220µF/200V/M/85 CEB2210S6016
C606 CERAMIC CAP. 680pF/2kV CA3D681PAN04
C607 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C608 CHIP CERAMIC CAP.(1608) B K 0.033µF/50V CHD1JK30B333
C609 CHIP CERAMIC CAP. B K 0.068µF/50V CHD1JK30B683
C610 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C611 CAP ELE 220µF/200V/M/85 CEB2210S6016
C612 CAP CERAMIC HV 1500PF 1kV B K CA3A152TE006
C614 CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C623 CHIP CERAMIC CAP.(1608) B K 4.7µF/6.3V CHD0KK30B475
C650 CAP CERAMIC HV 2200pF/1kV B K CA3A222TE006
C651 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C652 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C653 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C654 CAP ELE 470µF/16V/M/85 CEC4710V8006
C655 CAP ELE 470µF/16V/M/85 CEC4710V8006
C656 CAP ELE 4.7µF/50V/M/85 CEF4R70V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C662 CAP ELE 22µF/50V/M/85 CEF2200V8006
C663 CAP ELE 100µF/10V/M/85 CEB1010V8006
C667 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C668 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C1001 ELECTROLYTIC CAP. 470µF/25V M(105C) CE1EMASTH471
C1002 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1102 CAP ELE 470µF/25V/M/85 CED4710V8006
C1103 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1104 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1105 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1106 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1107 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1108 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1109 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1110 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1112 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1113 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1115 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1116 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1117 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1119 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1202 CAP ELE 470µF/25V/M/85 CED4710V8006
C1203 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1204 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1205 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1206 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1207 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1208 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1209 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1210 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1212 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1213 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1215 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1216 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1217 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1219 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1302 CAP ELE 470µF/25V/M/85 CED4710V8006
C1303 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1304 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1305 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1306 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1307 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1308 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1309 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1310 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1312 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1313 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1315 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1316 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1317 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1319 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
CONNECTORS
CN501 FFC CONNECTOR IMSA-9615S-23A-PP-A JC96J23ER007
CN601# CONNECTOR S2P3-VH (LF)(SN) JCVHC02JG002
CN1001 PH CONNECTOR TOP 6P B6B-PH-K-S
(LF)(SN)
J3PHC06JG029
DIODES
D601 DIODE 1N5406BH NDL1001N5406
D602 DIODE 1N5406BH NDL1001N5406
D603 DIODE 1N5406BH NDL1001N5406
D604 DIODE 1N5406BH NDL1001N5406
D605 ZENER DIODE MM5Z6V2B ND1BMM5Z6V2B
D606 DIODE FAST RECOVERY SMD GR1J-TR ND1Z00GR1JTR
D607A# ZENER DIODE SMD TFZGTR27B QD1B000TFZ27
Ref. No. Description Part No.
