Section 6: XTE3000 – RDM Operation Method
XTE3000 – RDM Operation Method
Section 6: XTE3000 – RDM Operation Method
a) RDM controls XTE3000
1. XTE3000 display and RDM display will both show as “REMOTE” when XTE3000
change selector knob in “REMOTE” position to have controlled by RDM.
2. XTE3000 display push button will have no function.
3. Open valve from RDM: Place RDM selector knob in “LOCAL” and move control
knob toward “OPEN”.
4. Close valve from RDM: Place RDM selector knob in “LOCAL” and move control
knob toward “CLOSE”.
5. Stop valve from RDM: Place RDM selector knob in “STOP”.
Figure 3
Close valve
Stop valve Open valve
