Universal replacement cores and lter cores for use in our ADKS and
STAS shells and similar competitive Take-Apart type Filter Drier shells.
May not be used for BTAS.
Features
• Water capacities to suit specic system conditions
• Exceptional acid capacities for normal system protection,
or to effectively clean-up following a compressor burnout
• Activated carbon blend for soluble contaminant and wax removal
(W-HH Series)
Nomenclature:
H 48
Series (in
3
)
Ordering Information:
PCN Type Refrigerant Function
Water Capacity
1
(g)
R 134a R 22 R 407C
R 404A
/R 507
R 410A
24
o
C 52
o
C 24
o
C 52
o
C 24
o
C 52
o
C 24
o
C 52
o
C 24
o
C 52
o
C
059541 D-48 HCFC High Acid Removal 20.8 17.0 18.2 12.7 11.3 4.8 22.9 17.2 10.5 4.3
059542 H-48 HCFC
High Acid and Water
Removal
33.8 26.9 29.9 21.8 22.3 14.3 36.1 26.8 19.0 11.3
061235 W-48-HH HCFC, HFC Burnout Cleanup 19.4 14.7 16.8 11.3 14.5 8.3 20.9 14.5 12.5 6.5
061617 UK-48
CFC, HCFC,
HFC
Universal Replacement 1272 1168 1181 1072 1033 786 1319 1241 976 707
089338 H-100 HCFC
High Acid and Water
Removal
55.6 41.7 48.1 33.7 36.3 20.9 60.0 42.0 33.6 18.2
043582 W-100-HH HCFC, HFC Burnout Cleanup 53.9 40.6 46.9 31.1 31.5 18.2 58.1 39.6 28.7 15.4
089559 F-48 HCFC, HFC Filter (Suction Only) -
095762 F-100 HCFC, HFC Filter (Suction Only) -
Note: 1. Water Capacities are based on Equilibrium Point Dryness (EPD) of:
50 parts per million for R 134a, R 404A/R 410A and R 407C, 60 parts per million for R 22
Filter drier
block size
Dimensions (mm)
Weight (kg)
A B C
42 152.4 40.1 79.2 0.5
48 139.7 45.0 94.5 0.7
100 165.1 52.3 122.2 2.0
Filter drier
block size
Dimensions (mm)
Weight (kg)
A B C
F48/F48R 140.0 71.4 98.6 0.3
F100 165.0 95.3 122.2 0.7
Cores And Filters
Filter-Drier Cores And Filters
Dimensional Data (mm):
Capacity Table (in Tons)
Liquid Line for Replaceable Block Type ADKS Filter Driers
Type
Connection
Size (inch)
Flow Capacity at 0.07 bar pressure drop
1,2
(kW)
R-12 R 134a R 22/R 410A R 407C R 404/507 R-502
ADKS 30013T
1 5/8 ODF
83
102
110
108
73
49
ADKS 30017T 2 1/8ODF 121 148 160 157 107 59
ADKS 40017T 2 1/8ODF 128 157 170 167 114 63
ADKS 40021T 2 5/8ODF 136 166 180 177 120 71
Notes:
1
All ratings in accordance with ARI Standard 710-04. 86°F liquid refrigerant temperature
5
o
F saturated vapor temperature
3.1 lbs./min./ton for R-134a
2.9 lbs./min./ton for R-22 and R-407C
4.0 lbs./min./ton for R-404A/507 and R-12
2
For 2 PSI ΔP. Multipy values by 1.4
