FB1100/FB1200 Flow Computer Termination Board Field Replacement Guide
D301820X012
March 2018
1
Removing/Replacing Termination Boards
CAUTION
MAY CAUSE INJURY TO PERSONNEL OR DAMAGE EQUIPMENT
Because I/O, ground, and other wires enter the flow computer through conduit fittings
and then connect to the termination board, a qualified technician must disconnect all
wiring coming into the flow computer and pull it out through the conduit fittings in
order to replace the termination board.
You must then install the new termination board and completely rewire the unit.
If not already done, be sure to label all wires before disconnecting so you can identify
them later during the rewiring process.
The FB1100 Flow Computer includes a single type of termination board that uses 6-
connector pluggable terminal blocks.
