Instruction Manual
D103292X012
C1 Controllers and Transmitters
March 2017
41
Parts Kits
Description Part Number
Controller Repair Kits
Kit includes Gasket, Relay Gasket, Bellows Frame
Gasket, and keys 16, 20, 21, 31, 37, 38, 40, 46, 49,
50, 54, 62, 75, 76, and 77
Note
Keys 71K, 71L, and 71M may also be necessary for repair of C1B and C1D
controllers. Refer to the Common Parts section for part numbers.
Standard Temperature RC100X00L12
High Temperature RC100X00H12
Relay Replacement Kits
Kit includes keys 19 and 29, the replacement relay, and
2 Machine Screws
Standard Temperature RRELAYX0L22
High Temperature RRELAYX0H22
Case Assembly Seal Kit
Kit includes 3 Manifold Seals, 1 Manifold Cover,
and 10 Mounting Screws RC100X00012
C1P Tubing Replacement Kit
Kit includes key 23, 24, 25, 26, and 27 RC100XTRK12
Parts List
Note
Contact your Emerson Automation Solutions sales office
for Part
Ordering information.
Common Parts (Figures 22, 23,
24, and 25)
Key Description
1 Case and Cover Assembly, aluminum
Key Description
Note
Key 2 is used as both a supply gauge and an output gauge on units
without a process pressure gauge. A quantity of 2 is required for these
units. On units with a process pressure gauge (key 106), key 2 is used for
the output gauge. A quantity of 1 is required for these units.
Use key 3 for supply pressure indication when a process pressure gauge
is installed. Key 3 installs on the supply pressure regulator.
2* Supply and Output Pressure Gauge, w/o process
pressure gauge (1/8-inch connecting stem), (2 req'd)
Dual scale
Brass/Plastic
0-2.0 kg/cm
2
and 0-30 psig
0-4.0 kg/cm
2
and 0-60 psig
SST
0-2.0 kg/cm
2
and 0-30 psig
0-4.0 kg/cm
2
and 0-60 psig
Triple scale
Brass/Plastic
0-2.0 bar, 0-0.2 MPa, and 0-30 psig
0-4.0 bar, 0-0.4 MPa, and 0-60 psig
SST
0-2.0 kg/cm
2
and 0-30 psig
0-4.0 kg/cm
2
and 0-60 psig
2* Output Pressure Gauge, w/process pressure
gauge (1/8-inch connecting stem), Brass/Plastic
Triple scale
0-2.0 bar, 0-0.2 MPa, and 0-30 psig
0-4.0 bar, 0-0.4 MPa, and 0-60 psig
3* Supply Pressure Gauge, w/process pressure
gauge (1/4-inch connecting stem), Brass/Plastic
Triple scale
0-2.0 bar, 0-0.2 MPa, and 0-30 psig
0-4.0 bar, 0-0.4 MPa, and 0-60 psig
Note
Controllers with bellows sensing element use only the 2.0 bar, 0 to 0.2
MPa, and 0 to 0 to 30 psig triple scale brass and stainless steel process
pressure gauges. Differential pressure controllers do not use a process
pressure gauge.
4* Process Pressure Indicator Gauge (use only when specified)
Triple scale
Stainless steel
0-2.0 bar, 0-0.2 MPa, and 0-30 psig
0-20 bar, 0-2.0 MPa, and 0-300 psig
0-69 bar, 0-6.9 MPa, and 0-1000 psig
High Temp, silicone
*Recommended spare parts
