Emerson MAS 2600 User Manual

MAS2600: Ordering Information Reference Manual
August 2023 RM 6000-01-001-24
21
Flange Mounting (dwg no. P022P013)
The standard transducer is supplied with DN25, DN40 or DN50 PN16 DIN2527 flange man-
ufactured of ASTM 316L steel.
Note! Maximum torque 20 Nm (slightly tighten by the hand + 1/8 to 1/4 turn).
Remember the gasket.
Flange Bolts
DN
D
mm
B
mm
K
mm
No. of bolts
Thread
diameter
d
mm
25 115 16 85 4 M12 14
40 150
16 110 4
M16 18
50 165 18
125 4
M16 18
TWO W IRE TRANSM ITTER
2600 SERIES
90-C.95948
T5
Cint = 10 nF
C
CERTIFICATE REF.:
4-20 mA
Lint = 20 uH
x i
EE
X a
MARINE AUTOMATION DENMARK
S/N :
Umax = 33 V
T amb.: -40 to +85 °C
I 45 mA
K =
<
2600
Ta nk t op
Tan k bo tt om
Bulkhead

19, 5
D
k
d
b

