Mentor MP User Guide 23
Issue: 3 www.controltechniques.com
Figure 3-12 Size 2D back-plate and mounting detail
1. M10 eye-bolts can be inserted in the location shown for lifting the drive. These are not supplied with the drive.
With the SMARTCARD installed to the drive, the depth measurement increases by 7.6mm (0.30 in).
53mm
(2.09in)
1065mm (41.93in)
288mm (11.34in)
450mm (17.72in)
394mm (15.51in)
1510mm (59.45in)
611mm (24.06in)
306mm (12.05in)
4 holes
to suit M10
35mm
(1.38in)
260mm
(10.24in)
180mm (7.09in)
180mm (7.09in)
90mm
(3.54in)
90mm
(3.54in)
68.5mm
(2.70in)
50mm
(1.97in)
190mm
(7.48in)
240mm
(9.45in)
333mm (13.11in)
8 holes
∅ 7mm
83.5mm
(3.29in)
210mm
(8.27in)
1
NOTE
NOTE
