IQ8 / IQ8+ / IQ8M / IQ8A / IQ8H Micro Installation and Operation
14 © 2022 Enphase Energy Inc. All rights reserved. Mar 2022
Enphase Microinverter Installation
Installing the Enphase IQ Series Micros involves several key steps. Each step listed here is detailed
in the following pages.
Step 1: Position the Enphase IQ Cable
Step 2: Position the Junction Box
Step 3: Mount the Microinverters
Step 4: Create an Installation Map
Step 5: Manage the Cabling
Step 6: Connect the Microinverters
Step 7: Terminate the Unused End of the Cable
Step 8: Complete Installation of the Junction Box
Step 9: Connect the PV Modules
Step 10: Enphase Energy System Configurations
Horizontal Mount
Vertical Mount
To Next Page
