Epson EB-X14 User Manual

a
If not all of the files and folders are displayed on the current
screen, press the [
]
] button on the remote control, or position
the cursor on Next Page at the bottom of the screen and press
the [
] button.
To return to the previous screen, press the [[] button on the
remote control, or position the cursor on Previous Page at the
top of the screen and press the [
] button.
b
Press the [ ] button.
The selected image is displayed.
When a folder is selected, the files in the selected folder are
displayed. To return to the previous screen, position the cursor on
Back to Top and press the [
] button.
Rotating images
You can rotate the played images in 90˚ increments. The rotating function
is also available during Slideshow.
a
Play images, or run Slideshow.
b
While projecting, press the [ ] or [ ] button.
Stopping Slideshow
To close Slideshow, disconnect the USB device from the USB port on the
projector. For digital cameras, hard disks, and so on, turn off the power to
the device and then remove.
Projecting the selected image
Attention
Do not disconnect the USB storage device while it is being accessed.
Slideshow may not operate correctly.
a
Start Slideshow.
The file list screen is displayed.
s "Starting Slideshow" p.47
Projection Functions
49

Epson EB-X14 Specifications

General

Native aspect ratio	4:3
Projection distance	1.1 - 10.8 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	±30 °
Projector brightness (economic mode)	2400 ANSI lumens
Focus	Manual
Throw ratio	1.48 - 1.77:1
Focal length range	17 - 20 mm
Lamp type	E-TORL
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
AC (power) in	Yes
Audio (L/R) in	-
Composite video in	0
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
RMS rated power	2 W
Noise level	37 dB
Preset modes	Dynamic, Presentation, sRGB, Vivid photo
Country of origin	China
Noise level (economic mode)	29 dB
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3964 g
