Disassembly/Reassembly Disassembly/Reassembly Procedures 32
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
2.2.1 Disassembly Flowchart
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series described in this manual have differences in
their structure because the same printer mechanism is used for some of them and the composition of housings or
functions differs.
The functions and differences according to the models are as follows.
Therefore, parts and units are colored and classified into 5 types in the flowchart given in this section.

Common parts/unit: Black
 L365/L366,L360/L362,L220/L222 Series: Blue
 L365/L366 Series: Red
 L310/L312,L130/L132 Series: Green
 L220/L222,L130/L132 Series: Orange
Table 2-2. Function List According to Models
Item
L365/L366
Series
L360/L362
Series
L220/L222
Series
L310/L312
Series
L130/L132
Series
Scanner O O O --- ---
Panel
Movable type O --- --- --- ---
Locked type --- O O --- ---
Button type --- --- --- O O
Wireless LAN O --- --- --- ---
Low cost parts --- --- O --- O
Disassembly Flowchart Start Position p 33 p 33 p 33 p 34 p 34
Table 2-3. Components According to Functions
Item Specification
Scanner
The shape and unit of components below differ due to the difference of specifications of Scanner Unit.
• Scanner Unit
•Hinge
• Housing Rear/Left/Right
•Main Board
• Shield Plate
Panel
The shape and unit of components below differ due to the difference of specifications of Panel Unit.
•Panel Unit
Wireless LAN
The following part is not mounted on the models without the Wireless LAN.
• Wireless LAN Module
Low cost parts
• CR Timing Belt
• CR Motor
•PF Motor
• Housings, others
