Registering and deleting projectors for monitoring
17
Registration by specifying an IP address (Manual
registration)
Procedure
A Right-click in Grouping view and select "New" - "Projector
(manual registration)".
The following window will be displayed.
If Detail list view is displayed, select "New" - "Projector (manual
registration)" from the Edit menu.
You can also carry out this operation by selecting New - Projector
(manual registration) from the Edit menu.
B Enter the IP address of the projector to be registered in the
"IP address" box and then click "Search". When the message
is displayed, click "OK".
If using a serial TCP/IP conversion adapter and cable to connect
the projector, select Use Serial TCP/IP conversion adaptor. Enter
the port number in Port Number and then click Search.
C After searching is complete, enter the information for the
projector to be registered while referring to the table below.
Display name Enter the name of the projector(s) to be displayed
in Grouping view or Detail list view. Up to a
maximum of 32 bytes can be entered. A space
cannot be used as the first character.
Display icon Select the icon(s) to be displayed in Grouping
view or Detail list view.
Parent group Select when registering a projector in a group. If
no groups have been created, this cannot be
selected.
s "Registering several projectors to a
monitoring group all at once" p.18
Projector
name
This shows the name that has been registered on
the projector.
IP address This shows the IP address that you entered in step
2.
Use Serial
TCP/IP
conversion
adaptor.
Select this if using a serial TCP/IP conversion
adapter to connect the projector.
To Next Page
