Requirements and Specifications
49
Specifications
Printer specifications
Printing
Printing method On-demand ink jet
Nozzle configuration Black 48 nozzles
Color 45 nozzles (15 each: cyan, magenta, yellow)
Print direction Bidirectional with logic seeking
Input buffer 12KB
Mechanical
Paper feed method Friction
Paper path Sheet feeder, top entry
Sheet feeder capacity 100 sheets of 17 lb (65.8 g/m
2
) paper
Dimensions Storage Width: 16.7 inches (424 mm)
Depth: 9.0 inches (229 mm)
Height: 6.8 inches (172 mm)
Printing Width: 16.7 inches (424 mm)
Depth: 18.1 inches (460 mm)
Height: 10.9 inches (277 mm)
Weight 5.47 lb (2.48 kg) without the ink cartridges
Electrical
Rated voltage (Universal Power
Supply)
AC 100 - 240 V
Input voltage range* 90 to 264 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.4 to 0.2 A
Power consumption Approximately 19 W (ISO10561 Letter Pattern)
Approximately 3.0 W Sleep mode
Approximately 2.7 W Power Off mode
