Epson tm-m30 User Manual

19
Chapter 2 Installation
2
Printer Network Settings
This chapter explains how to configure network settings such as the IP address of the printer. EpsonNet Config
is used to configure the network settings. (The explanations assume that Safari is used for the Web browser. If
you are using a different browser, proceed as appropriate for your browser.)
1
Connect the printer to the network and turn on the printer power.
2
Print a status sheet and check the current IP address.
To print a status sheet, hold down the push button at least 3 seconds when the printer is in the ready
status.
3
Start your Web browser. Enter the IP address that appears in the status sheet into the
address bar to start EpsonNet Config.
IP address: http://(IP address)/
4
The screen for inputting your [Name] and [Password] appears. Input these items,
then click [Log in].
When setting an IP address, make sure the IP address is not already in use for another network
device or computer.
The initial setting of "Name" and "Password" for EpsonNet Config are following.
 Name: epson
 Password: epson

Epson tm-m30 Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Bluetooth	Yes
USB connector	USB Type-A / USB Type-B
Standard interfaces	Bluetooth, Ethernet, NFC, USB
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Country of origin	China
Autocutter durability	1.5 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Power supply type	AC
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Supported paper width	58 - 80 mm
Storage temperature (T-T)	5 - 45 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	-20 - 60 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	190 mm
Package height	230 mm
Package weight	2040 g
Quantity per pack	1 pc(s)
Pallet width	800 mm
Pallet height	2070 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)

Weight and Dimensions

Width	127 mm
