Epson WorkForce AL-M200DN User Manual

Status Monitor (Windows Only)
You can check the printer status with Status Monitor. Double-click the Status Monitor printer icon on
the taskbar at the bottom right of the screen. The Printer Selection window appears, which displays
the printer name, printer connection port, printer status, and model name. Check the column Status
to know the current status of your printer.
Settings button: Displays the Settings window and allows you to modify the Status Monitor settings.
Click the name of the desired printer listed on the Printer Selection window. The Printer Status
window appears.
The Printer Status window alerts you when there is a warning or when an error occurs, for example,
when a paper jam occurs or toner is running low.
By default, the Printer Status window appears automatically when an error occurs. You can specify
the conditions for starting the Printer Status window in Printer Status Window Properties.
To change the pop-up settings for the Printer Status window:
1. Right-click the Status Monitor printer icon on the taskbar at the bottom right of the screen.
2. Select Printer Status Window Properties.
The Printer Status Window Properties window appears.
3. Select the type of the pop-up and then click OK.
You can also check the toner level of your printer and the job information on the Printer Status
window.
Status Monitor is installed along with print drivers.
Launcher (Windows Only)
Using the Launcher-Btype window, you can open the Status Window and Printer Setting
Utility.
To use the Launcher, select to install the Launcher when you install print drivers.
AL-M200 Series User’s Guide
Printer Management Software 23

Epson WorkForce AL-M200DN Specifications

General

Multi-Purpose tray	Yes
Total input capacity	250 sheets
Total output capacity	125 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	10 sheets
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PCL 6, PostScript 3
Color	No
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Safety	IEC60950-1, EN60950-1, IEC60825-1, EN60825-1
Quantity per pack	1 pc(s)
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Supported media weight(s)	60 - 163 g/m²
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	Port 9100, WSD, NDS Printserver
Sound power level (standby)	54.4 dB
Sound pressure level (quiet mode)	24.8 dB
Envelopes sizes	DL
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	50 W
Power consumption (printing)	450 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	EN55022, EN61000-3-2, EN61000-3-3
Product color	White
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	15 - 80 %
Operating relative humidity (H-H)	10 - 85 %
Bundled software	Epson Status Monitor
Pallet width	800 mm
Pallet height	2130 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	477 mm
Package width	442 mm
Package height	330 mm
Package weight	8320 g

Weight and Dimensions

Dimensions (WxDxH)	385 x 355.6 x 225 mm
