Epson WorkForce AL-M200DN User Manual

See Also:
“Configuring Wireless Network Settings (AL-M200DW only)” on page 40
Setting the IP Address
TCP/IP and IP Addresses
If your computer is on a large network, contact your network administrator for the appropriate TCP/
IP addresses and additional system settings information.
If you are creating your own small Local Area Network or connecting the printer directly to your
computer using Ethernet, follow the procedure for automatically setting the printer’s IP address.
Computers and printers primarily use TCP/IP protocols to communicate over an Ethernet network.
With TCP/IP protocols, eac h printer and computer must have a unique IP ad dress. It is important that
the addresses are similar, but not the same; only the last digit needs to be different. For example, your
printer can have the address 192.168.1.2 while your computer has the address 192.168.1.3. Another
device can have the address 192.168.1.4.
Many networks have a Dynamic Host Configuration Protocol (DHCP) server. A DHCP server
automatically programs an IP address into every computer and printer on the network that is
configured to use DHCP. A DHCP server is built into most cable and Digital Subscriber Line (DSL)
routers. If you use a cable or DSL router, see your router’s documentation for information on IP
addressing.
Automatically Setting the Printer’s IP Address
If the printer is connected to a small established TCP/IP network without a DHCP server, use the
installer on the Software Disc to detect or assign an IP address to your printer. For further instructions,
insert the Software Disc into your computer's CD/DVD drive. After the Installer starts, follow the
prompts for installation.
Note:
For the automatic installer to function, the printer must be connected to an established TCP/IP network.
Dynamic Methods of Setting the Printer’s IP Address
There are two protocols available for dynamically setting the printer’s IP address:
AL-M200 Series User’s Guide
Printer Connection and Software Installation 29

Epson WorkForce AL-M200DN Specifications

General

Multi-Purpose tray	Yes
Total input capacity	250 sheets
Total output capacity	125 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	10 sheets
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PCL 6, PostScript 3
Color	No
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Safety	IEC60950-1, EN60950-1, IEC60825-1, EN60825-1
Quantity per pack	1 pc(s)
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Supported media weight(s)	60 - 163 g/m²
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	Port 9100, WSD, NDS Printserver
Sound power level (standby)	54.4 dB
Sound pressure level (quiet mode)	24.8 dB
Envelopes sizes	DL
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	50 W
Power consumption (printing)	450 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	EN55022, EN61000-3-2, EN61000-3-3
Product color	White
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	15 - 80 %
Operating relative humidity (H-H)	10 - 85 %
Bundled software	Epson Status Monitor
Pallet width	800 mm
Pallet height	2130 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	477 mm
Package width	442 mm
Package height	330 mm
Package weight	8320 g

Weight and Dimensions

Dimensions (WxDxH)	385 x 355.6 x 225 mm
