Lower paper cassettes
Printer driver settings
Paper Size
User Defined Size
*1
Paper Source
Cassette 1, Cassette 2
*2
, Cassette 3
*2 *3
, Cassette 4
*2 *3
Paper Type Plain, Semi-Thick, Preprinted, Letterhead, Recycled, Color, Labels, Thick, Extra
Thick, Special
*1
76.2 × 127 mm at minimum and 215.9 × 355.6 mm at maximum for Cassette 1
139.7 × 210 mm at minimum and 215.9 × 355.6 mm at maximum for Cassette 2, Cassette 3, and Cassette 4
*2
Available only when the optional paper cassette unit is installed.
*3
Available only for AL-M400 Series.
Note:
❏ Depending on the quality of the non-standard size paper, the printing environment, or the printing
procedure, the paper might skew. Make a trial print run before you print on a lot of non-standard size
paper.
❏ Duplex printing is not available for Extra Thick.
❏ For Windows, access the printer driver, then select User Defined Size from the Paper Size list on the
Basic Settings tab. In the User defined Paper Size dialog box, adjust the Paper Width, Paper Length,
and Unit settings to match your custom paper. Then click OK and your custom paper size will be
saved.
❏ The saved paper sizes can only be used with the printer driver you saved them to. Even if multiple
printer names are set for a printer driver, the settings can be available only for the printer name in
which you saved the settings.
❏ When sharing the printer on a network, you cannot create User Defined Size at the client.
❏ If you cannot use the printer driver as explained above, make this setting at the printer by accessing
the control panel’s Printing Menu and selecting CTM (custom) as the Page Size setting.
Cancelling a Print Job
From the printer
To cancel a print job on the printer’s control panel, see “Canceling Printing” on page 109.
AL-M300/AL-M400 Series User's Guide
Printing Tasks 41
