Technical data
10/2011 1007368-04 Operating instructions – 63
6 Technical data
6.1 Power rating, electrical specifications
and noise level
!
The Safety Checked seal (GS seal) certifies that the tanning device fulfils the
requirements of the Equipment and Product Safety Act (GPSG). The test
mark is located on the type plate.
AFFINITY 500-S SUPER POWER
Power consumption rating with air conditioning:
Power consumption rating without air conditioning:
–
7800 W
Rated frequency: 50 Hz
Rated voltage: 400-415 V 3N~ 230-240 V ~3
Rated fuses: 3 x 16 A (time delay) 3 x 35 A (time delay)
Connecting line: H05VV-F 5G 4 mm²
or
H05VV-F 5G 6 mm²
Noise level 1m away from device: 67.8 dB(A)
Noise level inside the device: <81 dB(A)
Load on the acrylic glass panel: max. 135 kg
Weight: approx. 500 kg
AFFINITY 500-S TWIN POWER
Power consumption rating with air conditioning:
Power consumption rating without air conditioning:
–
10300 W
Rated frequency: 50 Hz
Rated voltage: 400-415 V 3N~ 230-240 V ~3
Rated fuses: 3 x 25 A (time delay) 3 x 50 A (time delay)
Connecting line: H05VV-F 5G 4 mm²
or
H05VV-F 4G 10 mm²
Noise level 1m away from device: 67.8 dB(A)
Noise level inside the device: <81 dB(A)
Load on the acrylic glass panel: max. 135 kg
Weight: approx. 525 kg
