3 TECHNICAL DATA
0444 408 331
- 12 -
© ESAB AB 2020
3 TECHNICAL DATA
Feed 3004
Mains voltage 42V, 50-60Hz
Power requirement 336VA
Motor current I
max
8A
Wire feed speed 32–984in./min (0.8–25.0m/min)
Torch connection EURO
Max. diameter wire bobbin 12in. (*17in.) (300mm / *440mm)
Wire dimension
Fe 0.030–1/16in. (0.8–1.6mm)
Ss 0.030–1/16in. (0.8–1.6mm)
Al 0.040 & 1/16in. (1.0 & 1.6mm)
Cored wire 0.035–1/16in. (0.9–1.6mm)
Weight 33.1lbs (15kg)
Dimensions l×w×h 27.2×10.8×16.6in. (690×275×420mm)
Operating temperature 14 to 104°F (-10 to +40°C)
Shielding gas All types intended for MIG/MAG welding
max pressure 73 PSI
Coolant ESAB ready mixed coolant
max pressure 73 PSI
Maximum permissible load at
60% duty cycle 630A
100% duty cycle 500A
Enclosure class IP23
*Accessories can be found in the "ACCESSORIES" chapter.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 104°F (40°C) or below.
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration
by solid objects or water.
Equipment marked IP23 is intended for indoor and outdoor use.
