Mig C141/ C151 Mag C171/ C201/ C251
© ESAB AB 2012
Wear parts
- 24 -
ba47w1
(W. F. Mechanism 0469 475 880)
Item Denomination Ordering no. Notes
A Feed roller
0469 517 001
0349 311 443
Ø 0.6-0.8mm Fe, cored wire, CuSi
Ø 1.0mm Al
B Liner
0700 200 099
0349 311 441
Fe, cored wire, CuSi
Al
C Contact tip
0700 200 063
0700 200 064
0349 311 442
Ø 0.6mm Fe
Ø 0.8mm Fe, cored wire, CuSi
Ø 1.0mm Al
The rollers are marked with wire dimension in mm, some are also marked with inch.
Welding with aluminium wires.
In order to weld with aluminium wires, proper rollers, nozzles and liners for aluminium
wires MUST be used. It is recommended to use 3m long welding gun for aluminium
wires, equipped with appropriate wear parts.
