Eubank EAA/EGA Wall Mount AC Installation & Operation Manual
03/2021 Rev.5
3.3 Installation Materials
Installation Kits
Eubank air conditioners are shipped with one 12 Ga. "L" shaped bottom bracket. If you have not yet
unpacked the unit, follow the instructions in section 2.1. All units have built-in full length mounting
anges. Therefore, use of mounting brackets is not required.
Kit Components:
1. One 12 Ga. "L"-shaped bottom bracket.
Accessories:
The package may include other factory-supplied items (optional) as follows on the next page:
Controllers/Thermostats
CommStat Touch HVAC Controller, Solid State Lead/Lag Controller ............................. P/N K/10439
CommStat 4 HVAC Controller, Solid State Lead/Lag Controller ...................................... P/N S/07846
CommStat 3 HVAC Controller, Solid State Lead/Lag Controller ...................................... P/N S/04581
Digital thermostat. 1 stage heat, 1 stage cool. 7 day programmable. Fan switch:
Auto & On. Auto-change over. Keypad lockout. Non-volatile program memory. ................ P/N 50123
Digital thermostat. 2 stage heat, 2 stage cool. 7 day programmable. Fan switch:
Auto & On. Auto-change over. Status LED’s. Backlit display.
Programmable fan. Non-volatile program memory. .............................................................. P/N 50107
Grilles/Wall Sleeves
Supply Grilles
EAA1020/1024 - 28” x 8” .................................................................................................... P/N 80675
(711 mm x 203 mm)
EAA1030/1036/1042/1048/1060/EGA1072 .......................................................................... P/N 80676
30” x 10” (762 mm x 254 mm)
EAA1060 Reverse Flow ....................................................................................................... P/N 93197
30” x 16” (762 mm x 406 mm)
Return Grilles
EAA1020/1024 ...................................................................................................................... P/N 80678
28” x 14” (711 mm x 356 mm)
EAA1030/1036/1042/1048/1060/EGA1072 .......................................................................... P/N 80679
30” x 16” (762 mm x 406 mm)
EAA1060 Reverse Flow ........................................................................................................ P/N 93198
30” x 10” (762 mm x 254 mm)
Return Filter Grilles
Used when lter must be changed from the interior. Not recommended for economizer equipped air
conditioners.
Note: Filter used in Return Filter Grille is 1” (25 mm) thick.
EAA1020/1024 ...................................................................................................................... P/N 80672
28” x 14” (711 mm x 356 mm)
EAA1030/1036/1042/1048/1060/EGA1072 .......................................................................... P/N 80673
30” x 16” (762 mm x 406 mm)
