EVAPCO AT Series - Lrc;Lrwb;Eco-LRWB 8 Wide Units

53
COIL CASING SECTION
FAN HOUSING
FAN BELT
MOTOR ACCESS DOOR
TEFC FAN MOTOR
MAKE-UP VALVE
WITH ADJUSTABLE FLOAT
ACCESS DOOR
FAN WHEEL
COLD WATER BASIN
RECIRCULATOR PUMP/
MOTOR ASSEMBLY
PUMP RISER PIPING
BLEED LINE AND VALVE
SUCTION STRAINER
SUCTION HOOD
FAN WRAPPER
FAN SHEAVE
WATER DISTRIBUTION
SPRAY BRANCH SUPPORT
COIL
COIL CONNECTIONS
P
UMP RISER PIPING
W
ATER DISTRIBUTION
S
PRAY BRANCH
D
R
IFT ELIMINATORS
DRIFT ELIMINATOR
SUPPORT
PAN SECTION
LRC/LRWB/eco-LRWB 8’ Wide Units
