5.8. GPIOConnections
5.8.1. GPIO Connector Pin-Out
The following table lists the GPIO connector pin-out:
1 Relay Out 4 14 Relay Out 4
2 Relay Out 3 15 Relay Out 3
3 Relay Out 2 16 Relay Out 2
4 Relay Out 1 17 Relay Out 1
5 IN + opto 4 18 IN - opto 4
6 IN + opto 3 19 IN - opto 3
7 IN + opto 2 20 IN - opto 2
8 IN + opto 1 21 IN - opto 1
9 I/O TTL 8 22 GND (Return I/O 8)
10 I/O TTL 7 23 GND (Return I/O 7)
11 I/O TTL 6 24 GND (Return I/O 6)
12 I/O TTL 5 25 GND (Return I/O 5)
13 + 5V 50mA max.
5.8.2. GP In Connections
GPI Triggers
The allocation of the XT3 server GPI triggers is performed in the Multicam Configuration
window, in the GPI tab. See the Configuration manual for detailed information on
allocating GPI triggers.
66 5. Hardware Installation and Cabling
EVS Broadcast Equipment S.A. Issue 11.02.A July 2013
