EVS XT-3 Technical Reference

Base Board Jumpers
The follow ing table lists the V3X base board jumpers and their respective function:
Jumper Function
ST1, ST2 These 2 jumpers must be installed on the last V3X board of the server
(that is on V3X #1, 2, or 3 if there are respectively 1, 2, or 3 V3X boards
installed in the server).
ST3
(SPARE)
«Parking» for ST1 and ST2 jumpers when they are not used.
ST4(only
on V3X
with
genlock)
Must be set to HiZ (or not installed).
Note that the Genlock Loop connector on the back panel of the server (if
available) must always be terminated with a 75 Ohm load if it is not used.
ST5 Defines the position of the board inside the server. It must be set to «1»
for a V3X with genlock, and to «2» or «3» for a V3X board without
genlock, depending on its position in the server.
Base Board LEDs
The following table lists the LEDs available on the V3X base board with the genlock
functionality:
LED Color Status Function
GLK — Off The genlock module is not initialized.
Green Blinking The genlock module is properly initialized, but no valid
genlock signal is detected.
On The module is initialized and a valid genlock signal is
detected.
Red Blinking There is a genlock problem.
On A resync is needed.
PSU
OK
Green On All voltages are present and in the allowed range.
— Off There is a voltage problem.
74 6. Boards Description
EVS Broadcast Equipment S.A. Issue 11.02.A July 2013
