EVS XT-3 Technical Reference

Connector SD mode HD mode
Connector
label
J2 SDI monitoring output (SD) SDI monitoring output
(HD)
Not wired
to the
backplane.
Used for
onboard
multiviewer
input.
J3 Loop-through for the SDI
input signal (SD)
Loop-through for the SDI
input signal
(SD, down-converted)
OUT B
J4 SDI monitoring output (SD) SDI monitoring output
(SD/HD)
CHAR
OUT
SD/HD
J5 Not used
or
SDI input (SD) in an XREC
configuration
Not used
or
SDI input (HD) in an
XREC configuration
IN B
J6 SDI program output
(SD, identical to J7)
HD SDI program output
(SD, identical to J7)
OUT
J7 SDI program output
(SD, identical to J6)
HD SDI program output
(HD, identical to J6)
OUT
J8 SDI input (SD) HD SDI input (HD) IN
J9 Alternate SDI input
(SD, for the internal loop)
Alternate HD SDI input
(HD, for the internal loop)
Not wired
to the
backplane.
J9 of
REC1 only
connected
to Loop
connector.
Note
The loops of the input signal are not genlocked.
