EVS XT-3 Technical Reference Hardware Manual

XT3 Series DISK RECORDER - Version 10.05 - Hardware Technical Reference Manual
Issue
10.05.D
EVS Broadcast Equipment SA – July 2011
75
3.5.2 A2/A4 BOARD
MULTIVIEWER
The multiviewer board is an option on XT3 servers.
Connectors
IN
The J2 connectors from the CODEC modules of the COHX
board are connected to the IN connectors of the
multiviewer board.
OUT1 HD The OUT HD connector of the
multiviewer board is
connected to the MULTIVIEWER HD SDI connector on the
rear panel of the server.
