Maintenance
1.Stopengineandwaitforallmovingpartstostop.
Engageparkingbrake.
2.Waituntilthemachinecoolsbeforecheckingthe
hydraulicoil.
3.Adjusttheseattothemostforwardpositionto
accessthecapsontheLHandRHhydrodrives.
4.Cleantheareaaroundhydraulicreservoircapand
removecap.
5.Wipethedipstickcleanandre-insertthecapback
intothehydro.Lightlytightenthecap.
6.Removethecapagainandcheckthelevelofthe
oilonthedipstick.SeeFigure45foroillevels.
g008606
Figure45
1.Full2.Add
Note:Theoillevelonthedipstickwillbe
incorrectiftheoilischeckedwhentheunitishot.
7.Ifthedipstickoillevelisatthe“add”markadd
ExmarkPremiumHydroOil.
8.Replacehydraulicreservoircapandtightenuntil
snug.DoNotovertighten.
CheckTirePressures
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Checktirepressureindrivetiresandpneumatic
casters.
3.Inatepneumaticcastersto13psi(90kPa).
Inatedrivetires:
•AllModelsExceptWingDeckModels:13
psi(90kPa)
•WingDeckModels:18psi(124kPa)
4.Semi-pneumaticcastertiresDoNotneedtobe
inated.
Note:DoNotaddanytypeoftirelinerorfoam
llmaterialtothetires.Excessiveloadscreatedby
foamlledtiresmaycausefailurestothehydrodrive
system,frame,andothercomponents.Foamlling
tireswillvoidthewarranty.
CheckConditionOfBelts
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Removeleftandrightbeltshieldsondeckandlift
upoorpantoinspectdeckdrivebelt.
3.Checkundermachinetoinspectthepumpdrive
belt.
Note:Noadjustmentsarerequiredforbelt
tension.
LubricateGreaseFittings
Note:Seechartforserviceintervals.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Lubricatettingswithonetotwopumpsof
NLGIgrade#2multi-purposegungrease.
Refertothefollowingchartforttinglocations
andlubricationschedule.
AllModelsExceptWingDeckModels
LubricationChart
Fitting
Locations
Initial
Pumps
Numberof
Places
Service
Interval
1.Deckand
PumpIdler
Pivots
12
Yearly
2.Front
Caster
Pivots
*0
2
*Yearly
63
