Exmark LAZER Z User Manual

Schematics
WingDeckLiftHydraulicDiagram
M
0.35 CC/REV
0.022 IN
3
/REV
221 BAR ±7
3200 PSI ±100
OR2
.020
OR1
.020
PORTS “A”, “B”, “C”
7/16-20 UNF
(#4 SAE)
FOLD
CYLINDERS
DECK LIFT
CYLINDER
2
3
4:1
RATIO
1
ABC
345 BAR ±7
5000 PSI ±100
g299104
90
