14|52 - BCSD EtherCAT Beta series EtherCAT Servo Drives | Ref.2107
Installation manual
1.2. Mains filters
It is recomended to insert a mains filter at each axis.
Use the noise filter manufactured by · SCHAFFNER · at the brake power input for servomotors
with holding brakes.
Relationship between servo drive power and noise filter current:
Note:
single-phase servo drive should apply a two-phase filter. A three-phase servo drive
should apply a three-phase filter.
Choose the right filter according the specifications of operating voltage, current, and
manufacturer.
Recommended noise filter of 400 Vac servo drive:
MANDATORY.
In order to comply with European Directive 2014/35/EU on Low Voltage (LVD) and
2014/30/EU on Electromagnetic Compatibility (EMC), it is mandatory to insert a
mains filter in the system.
SERVO DRIVE POWER NOISE FILTER CURRENT SERVO DRIVE POWER NOISE FILTER CURRENT
0.75 kW 4 A 2.0 kW 8 A
1.0 kW 4 A 3.0 kW 12 A
1.5 kW 6 A 5.0 kW 20 A
SERVO DRIVE MODEL · JIANLI · NOISE FILTER · SCHAFFNER · NOISE FILTER
BCSD-10DEG-EC DL-5EB FN3025HP-10-71
BCSD-15DEG-EC DL-10EB FN3025HP-10-71
BCSD-20DEG-EC DL-10EB
FN3025HP-10-71
BCSD-30DEG-EC DL-15EB3
FN3025HP-20-71
BCSD-50DEG-EC DL-25EB3
FN3025HP-30-71
