Installation manual
Beta series EtherCAT Servo Drives | Ref.2107 BCSD EtherCAT - 19|52
3. CABLES
The following cables are required to connect the system:
BSC-EC-
cable is sold separately.
BSC-EC-0.3 cable is sold separately.
This cable is not provided by FAGOR.
CABLE REFERENCE DESCRIPTION LENGTH
BSC-EC-
EtherCAT cable between CNCelite and BCSD-EC
drive
: 05/10/15 m
BSC-EC-0.3
EtherCAT cable between BCSD-EC drive and BCSD-EC
drive
300 mm
CABLE ACCESSORIES - LATHES MACHINES CABLE ACCESSORIES - MILLING MACHINES
BSC-EC-0.3 · 300 mm · 2x BSC-EC-0.3 · 300 mm ·
CABLE REFERENCE DESCRIPTION LENGTH
Standard cable
Communication USB 2.0 cable between BCSD-EC drive
and PC.
A
male connector to
Mini-B
male connector.
-
