1. Footswitch
2. Jewel Indicator
3. Output Jack
4. Time
5. Depth
6. Type Switch
7. Rate
8. Variation Switch
9. Feedback
10. Level
11. Dotted 1/8 Switch
12. Input Jack
13. Low Battery Indicator
14. LED Kill Switch
15. Dry Kill Switch
16. DC Power Connector
1
4
2
3
12
13
10
11
MIRROR IMAGE DELAY
TIME
DEPTH RATE FEEDBACK
LEVEL
TYPE DOTTED
1/8
DIGITAL
ANALOG
TAPE
ON
OFF
VARIATION
1
2
6
7
85 9
14
16
15
LEDs DRY KILL
9V DC
INPUT
