44
SPECIFICATIONS
TYPE PR 5141
POWER REQUIREMENTS 1,500 watts (max) 380 watts (typical)
POWER AMP OUTPUT
400
W into
8
Ω
800
W into
4
Ω/2Ω
INPUT IMPEDANCES 1MΩ (input) 10kΩ (aux In)
INPUT SENSITIVITY 25mVrms (input) 600mVrms (aux In, both channels driven) (for full power at 100Hz, with Gain/Master at “10” and EQ controls at “0”)
TONE CONTROLS Bass: ±15dB @ 80Hz Low-mid: ±12dB @ 280Hz High-mid: ±12dB @ 1.2kHz Treble: ±15dB @ 10kHz (“shelving” type)
SHAPE FILTER Bright: +13dB @ 10kHz Contour: +1dB @ 80Hz, -13dB @ 670Hz, +2dB @ 8kHz Vintage
: Dynamic compression (-9dB max) with low pass (-6dB/oct) @ 400Hz
EFFECTS LOOP
Nominal level: -10dB Send: 1kΩ (balanced)
Return:
22kΩ (balanced)
LINE OUT Max level: +7dBU Impedance: 600
Ω (balanced)
HEADPHONE OUTPUT 140mW into 16Ω/channel
FOOTSWITCHES Economy footswitch (included, PN 0994049000) Vintage footswitch (optional, PN 0994054000) LED footswitch (optional, PN 0994052000)
DIMENSIONS AND WEIGHT Width: 13.6” (34.5 cm) Height: 3” (7.6 cm) Depth: 7” (17.8 cm) Weight: 6 lbs. (2.72 kg)
Product specifications subject to change without notice.
ENGLISH
BLOCK DIAGRAM
For questions and troubleshooting,
contact a Fender specialist at:
--- (U.S. toll free)
--- (International)
