FENDT Saphir Series User Manual

03-5
both worn out.
- Coupling ball is new (diameter of 50), but
shells of friction pads (Fig. 14/ Pos.
k
) and
l
) of the AKS 2004/AKS 3004 are comple-
tely worn out.
• Determine the diameter of the coupling ball in
order to deduce how much the shells of the
friction pads of the AKS 2004/AKS 3004 are
worn out (diameter of ball may not be less
than 49 mm).
Bild./Fig. 19
Bild./Fig. 18
All maintenance work must be carried
out by service stations that have been
authorised by AL-KO!
Replacing the shells for friction pads
• Always replace both of the shells for friction
pads!
• AKS 2004/AKS 3004 must be unhitched.
• Remove the lateral friction pads.
• Pull the rubber cushion up (Fig. 20/Pos.
j
)
to remove it.
• Press the safety display (Fig. 20/Pos.
p
)
outward and hold it in place, e.g. with a SW
14 spanner (Fig. 20/Pos.
k
).
• Remove the cheese head screws (Fig. 20/
Pos.
l
).
• Press the shell of the friction pad (Fig. 20/Pos.
m
) inward and down to pull it out.
• To open the ball-shaped coupling: pull the
clutch grip (Fig. 20/Pos.
q
) upwards (open
position).
• Remove the countersunk screw (Fig. 20/Pos.
n
).
• Use a screwdriver to push the shell of the
friction pad (Fig. 20/Pos.
o
) inwards to push
it out of the ball socket.
A Torx spanner (T25/T30) is required to
unscrew Pos.
l
and
n
.
The new shells for the friction pads are inserted
in the reverse order.
• Torque up the bolts (Fig. 20/Pos.
l
and
n
)
to 5 Nm.
• Hang the rubber cushion (Fig. 20/Pos.
j
)
over the bottom, then the top of the inset
proles on the case.
• Attach the lateral friction pads.
Bild./Fig. 20
