FENDT Vario 936 User Manual

Manual No. 016-5030-043 Rev. A 5
Introduction
Kit Contents
This section contains a list of the components that are included in the SmarTrax MD kit. Before beginning the
system installation, compare the items in the kit with the components on this list. If you have questions about
the kit, contact your Raven dealer.
TABLE 1. SmarTrax MD Installation Kit (P/N 117-5030-043)
Picture Item Description Part Number Qty.
Not Pictured
Manual - Fendt 700, 800, and 900 Series
SmarTrax MD Installation
016-5030-043 1
Assembly - Ring Gear 063-4001-011 1
Assembly - Spline Adapter 063-4001-022 1
Trim - Ring Gear Protective 019-0159-590 1
Bracket - Node Mounting 107-0172-084 1
Bracket - Angle Mounting 107-0172-270 1
Bracket - Collar Weldment 116-0159-751 1
Bearing - 1/2” Plastic Flanged 325-0000-036 1
Screw - #10-16 x 3/4” Zinc Self-Tapping 310-1002-073 4

FENDT Vario 936 Specifications

General

Max Speed	60 km/h
Hydraulic System	Closed-center load sensing
Rated engine speed	2100 rpm
Tire Size (Rear)	650/65 R42
Transmission	CVT
Fuel Tank Capacity	660 liters
Engine	MAN
Wheelbase	3, 050 mm (120 inches)
Engine Power	360 hp (268 kW)
