20 ferrismowers.com
2. Locate the transmission release levers on the rear of the
unit.
• Models with 42" Mower Deck: The transmission
release levers (A, Figure 16) are located on the sides
of the bumpers.
• Models with 48" / 52" Mower Deck: The
transmission release levers (B) are located on the
rear of the unit beneath the bumper.
16
There is one transmission release lever on each
transmission. The transmission release levers open and
close the transmission bypass valves.
3. To open the transmission bypass valves (bypass
position):
• Models with 42" Mower Deck: Pull the transmission
lever towards the rear of the unit, then up in the
slot, and allow it to rest in the notch (C). Repeat this
process for the other side of the unit.
• Models with 48" / 52" Mower Deck: Pull the
transmission release lever out towards the rear of
the unit and then towards the center of the unit (D).
Repeat this process for the other side of the unit.
4. Pivot the ground speed control levers in from the START/
PARK position to the neutral ‘N’ position to disengage the
parking brake. The unit can now be pushed by hand.
5. After moving the unit, close the bypass valve (run
position):
• Models with 42" Mower Deck: Pull the transmission
release lever towards the rear of the unit, then down
in the slot, and then push it towards the front of the
unit (E). Repeat the process for the other side of the
unit.
• Models with 48" / 52" Mower Deck: Pull the
transmission release lever out towards the side of the
unit and then push forward (F). Repeat this process
for either side of the unit.
Note:Both transmission release levers must be in the same
position.
Attaching a Trailer
Secure the trailer with an appropriately sized clevis pin
(A, Figure 17) and clip (B). See OPERATOR SAFETYfor
additional safety information regarding towed equipment and
towing.
WARNING
Towing Hazard
Towed loads can be hazardous and cause loss of control
on slopes.
The surface being driven on greatly impacts traction and
stability. Wet or slippery surfaces can greatly reduce
traction and the ability to stop or turn. Carefully evaluate
the surface conditions before operating the unit with towed
equipment.
• The maximum gross (trailer & load) weight of the trailer
should not exceed 200 lbs (91 kg).
• The maximum tongue weight should not exceed 20 lbs
(9,1 kg).
• Do not operate on slope exceeding 5 degrees.
• Reduce speed and use extreme caution on slopes.
• Do not tow with a grass bagger attached.
17
Excessive towed loads can cause loss of traction and loss of
control on slopes. Reduce towed weight when operating on
slopes. The surface being driven on greatly impacts traction
and stability. Wet or slippery surfaces can greatly reduce
traction and the ability to stop or turn. Carefully evaluate the
surface conditions before operating the unit and trailer, and
never operate on slopes greater than 5°.
