Technical data
6
Insulation 12.51, 12.81 12.01, 12.11, 12.31 12.21, 12.22, 12.71, 12.91, 12.92
Dielectric strength between supply and contacts VAC 4,000 4,000 4,000
Dielectric strength between open contacts VAC 1,000 1,000 1,000
Rated impulse voltage (between supply and contacts) kV/(1.2/50) s 6 6 6
Rated impulse voltage (between open contacts) kV/(1.2/50) s 1.5 1.5 1.5
EMC specifications
Type of test Reference standard
Electrostatic discharge contact discharge EN 61000-4-2 4 kV 6 kV
air discharge EN 61000-4-2 8 kV 8 kV
Radiated electromagnetic field (80…1,000 MHz) EN 61000-4-3 10 V/m 10 V/m
Fast transients (burst 5/50 ns, 5 and 100 kHz) EN 61000-4-4 4 kV 4 kV
Voltage pulses on supply terminals common mode EN 61000-4-5 4 kV 2 kV
(surge 1.2/50 µs) differential mode EN 61000-4-5 4 kV 2 kV
Radiofrequency common mode voltage (0.15…80 MHz) EN 61000-4-6 10 V 10 V
Voltage dips 70 % U
N
, 40 % U
N
EN 61000-4-11 10 cycles 10 cycles
Short interruptions EN 61000-4-11 10 cycles 10 cycles
Radio frequency conducted emissions 0.15…30 MHz EN 55014 class B class B
Radiated emissions 30…1,000 MHz EN 55014 class B class B
Terminals
Screw torque Nm 0.8 1.2
12.51, 12.81 12.01, 12.11, 12.31
Max. wire size mm
2
AWG mm
2
AWG
solid cable 1 x 6 / 2 x 4 1 x 10 / 2 x 12 1 x 6 / 2 x 4 1 x 10 / 2 x 12
stranded cable 1 x 4 / 2 x 2.5 1 x 12 / 2 x 14 1 x 6 / 2 x 2.5 1 x 10 / 2 x 14
12.21, 12.22, 12.71, 12.91, 12.92
Max. wire size mm
2
AWG
solid cable 1 x 6 / 2 x 4 1 x 10 / 2 x 12
stranded cable 1 x 6 / 2 x 2.5 1 x 10 / 2 x 14
Wire strip length mm 9
Other data
Power back-up (Battery life) 6 years (12.51, 12.81, 12.21, 12.22, 12.71, 12.91, 12.92)
Battery type CR 2032, 3V, 230 mAh
Power back-up 100 h (12.01, 12.11, 12.31 - following 80 h continuous energisation)
Power lost to the environment 12.51, 12.81 12.01, 12.11, 12.31 12.21, 12.22, 12.71, 12.91, 12.92
in stand-by W 1.4 — —
without contact current W 2.9 1.5 2
with rated current W 3.5 2.5 3 (for 1 pole)/4 (for 2 pole)
I-2014, www.findernet.com
12
SERIE S
12 Series - Time switches 16 A
